Crystalix Lite (CX75P)

Crystalix Lite is the lightest model in the CONERGIES CX series at 7.5 mil thickness. Its flexible construction makes installation easier on complex surfaces, making it ideal for daily drivers and vehicles in low to moderate impact environments. Built with CT·X polymerization substrate and CRYSTALIX bionic nano-coating, it is available with either a hydrophobic finish for water beading and self-cleaning or a hydrophilic finish for reduced water spotting. Both deliver enhanced gloss and surface depth. The multi-layer composite structure resists stone impacts, UV aging and chemical corrosion.

Available Sizes

*Custom lengths available Maximum width: 5 ft

5ft x 10ft (1.52 x 3m) ｜ 5ft x 15ft (1.52 x 5m) ｜ 5 ft × 50 ft (1.52 x 15m)  

Packaging

Rolled format, double boxed

Color

Transparent

Finish

High gloss

Shop

Find a Dealer

Become a Dealer

Product Highlights

Designed for both dry and wet installation methods. Dry application is recommended when used in combination with the supplied Conergies TackEase Wet Wipes.

Wet Application Optimized OEM Paint Gloss Enhancement Ultra Clear, Low Orange Peel Finish Self Healing Surface Technology TPU Based Construction All Weather Paint Protection Automotive Acrylic Adhesive System Installer Friendly Handling High Elasticity for Complex Panels 10 Year Warranty

Film Structure

The film is built using a multi-layer PPF architecture designed for both protection and aesthetics.

Material Characteristics

Automotive optical grade TPU clear paint protection film Hydrophilic Crystalix nano coating with self-healing capability High gloss, high clarity surface with reduced orange peel Wet application optimized adhesive behavior Repositionable during installation for precise alignment High elasticity allowing complex panel coverage without stress marks

Installation Guidelines

Recommended tools

Squeegee

knife

Masking tape

Heat gun

Gloves

Storage Guidelines

Product Name

Clear Paint Protection Film

Recommended Storage Temperature

15–25°C (59–77°F)

Recommended Storage Humidity

45–50%

Storage Environment

Store in a clean, indoor environment, free from excessive or visible dust and airborne particles.

All products must be stored in their original packaging and protected by the original protective materials.

Store rolls in a sealed, vertical position, away from direct sunlight and heat sources.

After opening, remove the surface protection layer from any remaining film to prevent warping or fogging.

Strict temperature and humidity control is essential to maintain product performance and stability.

Storage and installation must follow specified guidelines to ensure long term durability.

Warranty coverage is valid only when usage, storage, and maintenance guidelines are followed.

Physical Performance Indicators

Property	Specification	Standard / Reference
Gloss	≥ 90°	GB 8807
Water Contact Angle	≥ 65°	GB/T 30693
Weight (Finished Product)	360-390 g/m²	GB/T 4669
Weight (Adhesive)	25-30 g/m²	GB/T 4669
Overall Thickness	191.5 μm	GB/T 7125
Thickness (Removable PET Layer)	50 μm	GB/T 7125
Crystalix Nano Coating Thickness	6.5 μm	GB/T 7125
Aliphatic TPU Layer Thickness	160 μm	GB/T 7125
Adhesive Thickness	25 μm	GB/T 7125
	75 μm	GB/T 7125
Break Elongation	≥ 350%	GB/T 1040.1
Break Elongation (Crystalix Layer, MD)	≥ 85%	GB/T 1040.1
UV Barrier	≥ 95%	GB/T 2680, GB/T 4669
Tensile Strength	≥ 19 MPa	GB/T 1040
Release Force	≤ 0.3 N/25 mm	GB/T 2792
Peel Strength	≥ 1100 gf	GB/T 2792
