Laser Series

Our Laser Series is a holographic PPF for shops whose customers want prismatic highlights rather than a solid color or a mirror finish. As light crosses the bodywork, the film reveals changing reflections over its color finish. Its aliphatic TPU construction adds a protective layer over the paint, giving you a distinct option for custom builds where the effect itself is part of the brief.

Available Sizes

*Custom lengths available Maximum width: 5 ft

5ft x 10ft (1.52 x 3m) ｜ 5ft x 15ft (1.52 x 5m) ｜ 5 ft × 50 ft (1.52 x 15m)  

Packaging

Rolled format, double boxed

Finish

Color

Shop

Find a Dealer

Become a Dealer

Product Highlights

Subtle prismatic reflections change with lighting and viewing angle, creating a distinctive appearance for complete vehicle transformations.

A smooth surface and even visual texture give the prismatic effect a refined.

The HYPEROPTICOAT topcoat encourages water to spread across the surface and allows light surface scratches and swirl marks to recover with heat.

Color layers sit between two aliphatic TPU layers, combining the decorative finish with a flexible protective structure.

Helps protect painted surfaces against stone chips, light scratches, and environmental contaminants during everyday driving.

Supports controlled application and secure bonding, with air-release channels that help release trapped air during dry installation.

Engineered to withstand weather exposure, temperature fluctuations, and prolonged UV radiation while maintaining color stability and surface clarity.

Supplied CONERGIES TackEase wipes assist dry installation by temporarily reducing initial tack on suitable panel areas.

Flexible TPU supports application across curved and complex panels. Controlled stretching and tension management help maintain a consistent finish.

Supported by the CONERGIES limited warranty, subject to the applicable product, region, installation, and care requirements.

Prismatic Laser Finishes Unique Prismatic Effect Hydrophilic, Self-Healing Coating Encapsulated Color Construction Everyday Paint Protection Automotive Acrylic Adhesive Installer-Friendly Application  TackEase Installation Support Flexible Panel Conformability Limited Warranty Coverage

Film Structure

The film is built using a multi-layer PPF architecture designed for both protection and aesthetics.

Material Characteristics

Aliphatic TPU construction Hydrophilic, self-healing HYPEROPTICOAT topcoat Laser finish with subtle prismatic reflections Color layers encapsulated between two TPU layers Flexible handling for curved and complex panels Automotive acrylic adhesive with air-release channels

Installation Guidelines

Recommended tools

Squeegee

Knife

Masking tape

Heat gun

Gloves

Storage Guidelines

Product Name

Color Paint Protection Film

Recommended Storage Temperature

15–25°C (59–77°F)

Recommended Storage Humidity

45–50%

Storage Environment

Store in a clean, indoor environment, free from excessive or visible dust and airborne particles.

All products must be stored in their original packaging and protected by the original protective materials.

Store rolls in a sealed, vertical position, away from direct sunlight and heat sources.

After opening, remove the surface protection layer from any remaining film to prevent warping or fogging.

Strict temperature and humidity control is essential to maintain product performance and stability.

Storage and installation must follow specified guidelines to ensure long term durability.

Warranty coverage is valid only when usage, storage, and maintenance guidelines are followed.

Physical Performance Indicators

Property	Specification	Standard / Reference
Gloss	≥ 90° GU	GB 8807
Weight (Finished Product)	355–395 G/M²	GB/T 4669
Weight (Adhesive)	25–30 g/m²	GB/T 4669
Overall Thickness	183.88–208.13 μm	GB/T 7125
Thickness (Removable PET Layer)	45–55 μm	GB/T 7125
HOC Top Coating Thickness	9.5–10.5 μm	GB/T 7125
Aliphatic TPU Film (> UV90 Protection)	57–63 μm	GB/T 7125
Grade 8 UV Protection Top Color Layer	16.63–18.38 μm	GB/T 7125
Grade 8 UV Protection Base Color Layer	10.5–16.5 μm	GB/T 7125
Aliphatic TPU Base Film	57–63 μm	GB/T 7125
Adhesive Thickness	33.25–36.75 μm	GB/T 7125
Thickness (PET Liner)	75–85 μm	GB/T 7125
Break Elongation (HOC Layer, MD)	≥ 60%	GB/T 1040.1
Dimensional Stability (MD)	≤ 0.5 mm	FTM 14
Dimensional Stability (CD)	≤ 0.4 mm	FTM 14
Peel Force (Finished Product)	≤ 0.3 N/25 mm	GB/T 2792
Initial Adhesion	≥ 8 N/25 mm	FTM 9
24 H 180° Peel Force	≥ 12 N/25 mm	GB/T 2792
Storage Aging Peel Force	≥ 10 N/25 mm	GB/T 2792
Application Aging Peel Force	≥ 16 N/25 mm	GB/T 2792

Laser Series FAQs

How is the Laser Series different from the Color Shift Series?

Laser Series produces prismatic highlights across the finish. The Color Shift Series changes the film's visible tone as the viewing angle changes.

Will the holographic effect be equally visible in all lighting?

No. The reflections change with the light source and viewing angle. They may appear subtler under diffuse light.

Will the effect look the same on a flat door and a curved fender?

No. The panels face the light at different angles, so their prismatic reflections will appear different.

Are the color layers exposed on the surface of the film?

No. The color layers are enclosed between two aliphatic TPU layers. A self-healing topcoat forms the outer surface.

Can light scratches in Laser Series PPF self-heal?

Light scratches and swirl marks in the topcoat may recover with heat. Damage through the topcoat will not.
