Structured Textures Series

Our Structured Textures Series gives your shop carbon fiber PPF looks and other material-inspired finishes without replacing the vehicle’s painted panels. Defined patterns add depth that a solid color cannot, while the flexible TPU film provides a protective layer over the paint. The Structured Textures Series helps protect painted surfaces against stone chips, light scratches, and environmental contaminants.

Available Sizes

*Custom lengths available Maximum width: 5 ft

5ft x 10ft (1.52 x 3m) ｜ 5ft x 15ft (1.52 x 5m) ｜ 5 ft × 50 ft (1.52 x 15m)  

Packaging

Rolled format, double boxed

Finish

Color

Shop

Find a Dealer

Become a Dealer

Product Highlights

Patterns inspired by carbon fiber and stone create a distinctive appearance for complete vehicle transformations.

Visual depth and defined pattern detail give each finish the character of the material it represents.

The HYPEROPTICOAT topcoat encourages water to spread across the surface and allows light surface scratches and swirl marks to recover with heat.

Color layers sit between two aliphatic TPU layers, combining the decorative finish with a flexible protective structure.

Helps protect painted surfaces against stone chips, light scratches, and environmental contaminants during everyday driving.

Supports controlled application and secure bonding, with air-release channels that help release trapped air during dry installation.

Supports both application methods, allowing installers to select an approach suited to the panel shape and installation conditions.

Supplied CONERGIES TackEase wipes assist dry installation by temporarily reducing initial tack on suitable panel areas.

Flexible TPU supports application across curved and complex panels. Controlled stretching and tension management help maintain a consistent finish.

Supported by the CONERGIES limited warranty, subject to the applicable product, region, installation, and care requirements.

Material-Inspired Finishes Dimensional Surface Appearance Hydrophilic, Self-Healing Coating Encapsulated Color Construction Everyday Paint Protection Automotive Acrylic Adhesive Dry or Wet Installation Options TackEase Installation Support Flexible Panel Conformability Limited Warranty Coverage

Film Structure

The film is built using a multi-layer PPF architecture designed for both protection and aesthetics.

Material Characteristics

Aliphatic TPU construction Hydrophilic, self-healing HYPEROPTICOAT topcoat Material-inspired patterns with visual depth and texture Color layers encapsulated between two TPU layers Flexible handling for curved and complex panels Automotive acrylic adhesive with air-release channels

Installation Guidelines

Recommended tools

Squeegee

Knife

Masking tape

Heat gun

Gloves

Storage Guidelines

Product Name

Color Paint Protection Film

Recommended Storage Temperature

15–25°C (59–77°F)

Recommended Storage Humidity

45–50%

Storage Environment

Store in a clean, indoor environment, free from excessive or visible dust and airborne particles.

All products must be stored in their original packaging and protected by the original protective materials.

Store rolls in a sealed, vertical position, away from direct sunlight and heat sources.

After opening, remove the surface protection layer from any remaining film to prevent warping or fogging.

Strict temperature and humidity control is essential to maintain product performance and stability.

Storage and installation must follow specified guidelines to ensure long term durability.

Warranty coverage is valid only when usage, storage, and maintenance guidelines are followed.

Physical Performance Indicators

Property	Specification	Standard / Reference
Gloss	≥ 90°	GB 8807
Weight (Finished Product)	355–395 G/M²	GB/T 4669
Weight (Adhesive)	25–30 g/m²	GB/T 4669
Overall Thickness	183.88–208.13 μm	GB/T 7125
Thickness (Removable PET Layer)	45–55 μm	GB/T 7125
HOC Top Coating Thickness	9.5–10.5 μm	GB/T 7125
Aliphatic TPU Film (> UV90 Protection)	57–63 μm	GB/T 7125
Grade 8 UV Protection Top Color Layer	16.63–18.38 μm	GB/T 7125
Grade 8 UV Protection Base Color Layer	10.5–16.5 μm	GB/T 7125
Aliphatic TPU Base Film	57–63 μm	GB/T 7125
Adhesive Thickness	33.25–36.75 μm	GB/T 7125
Thickness (PET Liner)	75–85 μm	GB/T 7125
Break Elongation (HOC Layer, MD)	≥ 60%	GB/T 1040.1
Dimensional Stability (MD)	≤ 0.5 mm	FTM 14
Dimensional Stability (CD)	≤ 0.4 mm	FTM 14
Peel Force (Finished Product)	≤ 0.3 N/25 mm	GB/T 2792
Initial Adhesion	≥ 8 N/25 mm	FTM 9
24 H 180° Peel Force	≥ 12 N/25 mm	GB/T 2792
Storage Aging Peel Force	≥ 10 N/25 mm	GB/T 2792
Application Aging Peel Force	≥ 16 N/25 mm	GB/T 2792

Structured Textures Series FAQs

Is carbon fiber PPF made from real carbon fiber?

No. Here, “carbon fiber” describes the film’s appearance, not a structural carbon-fiber component. The series is a TPU color paint protection film with material-inspired visual layers.

How does a forged carbon PPF look differ from a woven carbon-fiber pattern?

A woven look has a regular, repeating weave; a forged-carbon look has a less uniform, fragmented pattern.

What should a shop plan before quoting a full-vehicle textured PPF installation?

Choose the exact pattern first. Then map how it will meet across the hood, fenders, doors, and mirrors, including any visible joins and the direction of the design. That layout determines the material allowance and gives the customer a realistic view of the finished result.

Can carbon fiber paint protection film be used only on selected panels?

Yes, selected-panel accents are an option alongside a broader transformation. Show where the textured film will meet uncovered paint, and agree on complete-panel coverage and edge treatment before the work begins.

Can the Structured Textures Series be installed wet or dry?

The series supports both methods. CONERGIES supplies TackEase wipes to support dry application, but choose the method based on the panel shape and current installation instructions.
