DiamondClear Hydro is a 7.5 mil clear paint protection film designed to provide a balance of optical clarity, flexible handling, and reliable everyday protection. Its conformable construction supports installation across curved and complex panels, making it well suited to daily-driven vehicles exposed to low-to-moderate impact conditions.
Engineered with CT·X optical-grade TPU and a hydrophobic CRYSTALIX nano coating, DiamondClear Hydro enhances the depth and gloss of the original paint while promoting water beading and easier routine cleaning. It helps protect painted surfaces against stone chips, light scratches, environmental contaminants, and prolonged UV exposure.
| Property | Specification | Standard / Reference |
|---|---|---|
| Gloss | ≥ 90° GU | GB 8807 |
| Water Contact Angle | ≥ 90° | GB/T 30693 |
| Weight (Finished Product) | 360-390 g/m² | GB/T 4669 |
| Weight (Adhesive) | 25-30 g/m² | GB/T 4669 |
| Overall Thickness | 191.5 μm | GB/T 7125 |
| Thickness (Removable PET Layer) | 50 μm | GB/T 7125 |
| Crystalix Nano Coating Thickness | 6.5 μm | GB/T 7125 |
| Aliphatic TPU Layer Thickness | 160 μm | GB/T 7125 |
| Adhesive Thickness | 25 μm | GB/T 7125 |
| Thickness (PET Liner) | 75 μm | GB/T 7125 |
| Break Elongation | ≥ 350% | GB/T 1040.1 |
| Break Elongation (Crystalix Layer, MD) | ≥ 85% | GB/T 1040.1 |
| UV Barrier | ≥ 95% | GB/T 2680, GB/T 4669 |
| Tensile Strength | ≥ 19 MPa | GB/T 1040 |
| Release Force | ≤ 0.3 N/25 mm | GB/T 2792 |
| Peel Strength | ≥ 1100 gf | GB/T 2792 |
Both are 7.5 mil clear gloss paint protection films. DiamondClear Hydro features a hydrophobic topcoat that promotes water beading, while DiamondClear features a hydrophilic topcoat that encourages water to spread across the surface. The main distinction is how the surface interacts with water, rather than film thickness or gloss finish.
A separate ceramic coating is not required to give DiamondClear Hydro its hydrophobic finish. Water repellency is already built into the film’s topcoat. For customers considering an additional coating, contact Conergies to confirm compatibility before application.
No. The nominal 7.5 mil thickness includes the topcoat, TPU film and adhesive: the layers that remain on the vehicle. The removable protective capsheet and release liner are excluded from this measurement.
DiamondClear Hydro’s heat-responsive topcoat allows light surface scratches and swirl marks to recover. Self-healing applies to superficial marks in the coating, not deep cuts, punctures or damage to the underlying paint. It helps maintain the film’s appearance but does not make it scratch-proof.
DiamondClear Hydro is engineered for high optical clarity and minimal surface texture, keeping the film’s own orange-peel appearance to a minimum. Its clear, high-gloss finish is designed to enhance the appearance of the original paint without adding a pronounced textured look.
