Chrome Series

Our Chrome Series is chrome PPF for shops, offering a mirror-like color change with paint protection built in. Its reflective finish gives custom and promotional vehicles a look that ordinary metallic film cannot produce. Its mirror-like finish emphasizes the vehicle’s contours, creating a bold, polished appearance for complete vehicle transformations. Powered by self-healing HYPEROPTICOAT and premium TPU, the Chrome Series shields your paint from chips, scratches, and stains.

Available Sizes

*Custom lengths available Maximum width: 5 ft

5ft x 10ft (1.52 x 3m) ｜ 5ft x 15ft (1.52 x 5m) ｜ 5 ft × 50 ft (1.52 x 15m)  

Packaging

Rolled format, double boxed

Finish

Color

Shop

Find a Dealer

Become a Dealer

Product Highlights

Chrome finishes create a bold metallic appearance for complete vehicle transformations.

A smooth, highly reflective surface produces defined reflections that emphasize the vehicle’s contours.

The HYPEROPTICOAT topcoat encourages water to spread across the surface and allows light surface scratches and swirl marks to recover with heat.

Color layers sit between two aliphatic TPU layers, combining the decorative finish with a flexible protective structure.

Helps protect painted surfaces against stone chips, light scratches, and environmental contaminants during everyday driving.

Supports controlled application and secure bonding, with air-release channels that help release trapped air during dry installation.

Supports both application methods, allowing installers to select an approach suited to the panel shape and installation conditions.

Supplied CONERGIES TackEase wipes assist dry installation by temporarily reducing initial tack on suitable panel areas.

Flexible TPU supports application across curved and complex panels. Controlled stretching and tension management help maintain a consistent finish.

Supported by the CONERGIES limited warranty, subject to the applicable product, region, installation, and care requirements.

Chrome Finishes Smooth, Mirror-Like Finish Hydrophilic, Self-Healing Coating Encapsulated Color Construction Everyday Paint Protection Automotive Acrylic Adhesive Dry or Wet Installation Options TackEase Installation Support Flexible Panel Conformability Limited Warranty Coverage

Film Structure

The film is built using a multi-layer PPF architecture designed for both protection and aesthetics.

Material Characteristics

Aliphatic TPU construction Hydrophilic, self-healing HYPEROPTICOAT topcoat Highly reflective chrome finish with a mirror-like appearance Color layers encapsulated between two TPU layers Flexible handling for curved and complex panels Automotive acrylic adhesive with air-release channels

Installation Guidelines

Recommended tools

Squeegee

Knife

Masking tape

Heat gun

Gloves

Storage Guidelines

Product Name

Color Paint Protection Film

Recommended Storage Temperature

15–25°C (59–77°F)

Recommended Storage Humidity

45–50%

Storage Environment

Store in a clean, indoor environment, free from excessive or visible dust and airborne particles.

All products must be stored in their original packaging and protected by the original protective materials.

Store rolls in a sealed, vertical position, away from direct sunlight and heat sources.

After opening, remove the surface protection layer from any remaining film to prevent warping or fogging.

Strict temperature and humidity control is essential to maintain product performance and stability.

Storage and installation must follow specified guidelines to ensure long term durability.

Warranty coverage is valid only when usage, storage, and maintenance guidelines are followed.

Physical Performance Indicators

Property	Specification	Standard / Reference
Gloss	≥ 90°	GB 8807
Weight (Finished Product)	355–395 G/M²	GB/T 4669
Weight (Adhesive)	25–30 g/m²	GB/T 4669
Overall Thickness	183.88–208.13 μm	GB/T 7125
Thickness (Removable PET Layer)	45–55 μm	GB/T 7125
HOC Top Coating Thickness	9.5–10.5 μm	GB/T 7125
Aliphatic TPU Film (> UV90 Protection)	57–63 μm	GB/T 7125
Grade 8 UV Protection Top Color Layer	16.63–18.38 μm	GB/T 7125
Grade 8 UV Protection Base Color Layer	10.5–16.5 μm	GB/T 7125
Aliphatic TPU Base Film	57–63 μm	GB/T 7125
Adhesive Thickness	33.25–36.75 μm	GB/T 7125
Thickness (PET Liner)	75–85 μm	GB/T 7125
Break Elongation (HOC Layer, MD)	≥ 60%	GB/T 1040.1
Dimensional Stability (MD)	≤ 0.5 mm	FTM 14
Dimensional Stability (CD)	≤ 0.4 mm	FTM 14
Peel Force (Finished Product)	≤ 0.3 N/25 mm	GB/T 2792
Initial Adhesion	≥ 8 N/25 mm	FTM 9
24 H 180° Peel Force	≥ 12 N/25 mm	GB/T 2792
Storage Aging Peel Force	≥ 10 N/25 mm	GB/T 2792
Application Aging Peel Force	≥ 16 N/25 mm	GB/T 2792

Chrome Series FAQs

How is chrome PPF different from a chrome vinyl wrap?

Chrome PPF is a TPU paint protection film with a reflective finish. Chrome vinyl wrap is primarily used to change a vehicle’s appearance. The main difference is that PPF also places a protective film over the paint.

Will chrome PPF have the same mirror effect on flat and curved panels?

No. A curved panel reflects its surroundings differently from a flat one, so the mirror effect will look different across the vehicle.

Can Chrome Series film be installed wet or dry?

Yes. CONERGIES lists both methods. Its supplied TackEase wipes are intended to assist dry installation.

Can scratches in chrome PPF self-heal?

Light marks in the topcoat may recover with heat. Deep cuts or damage through the film will not.

What warranty applies to the Chrome Series?

It falls under CONERGIES’ limited ColorPPF warranty against qualifying manufacturing defects. The stated period is 10, 8, or 5 years, depending on the installation region; road damage and normal wear are not covered.
